BMPCC4K

Kondor Blue’s top handle has been tested with popular cameras such as RED KOMODO, Canon EOS R/R5/R6, Fuji X-T4, C500, C70, C300, Z CAM Flagship, URSA Mini Pro, GH5, LUMIX S1H, Sony A7 Cameras, and many more!

*Includes a 2.5 to 2.5 LANC cable and a 2.5 to micro USB remote cable.

(Komodo and N3 Shutter cables must be purchased separately unless purchased with a cage as a bundle.)

Top Trigger Handle Features:

• Start/Stop Record Button. Supports both Sony LANC and Panasonic Protocols providing Compatibility for most cameras such as Z CAM, Blackmagic, Fuji, Sony, Canon, Panasonic, JVC, etc.
• Five 3/8" threaded holes with ARRI Locator Pins for Antitwist Accessories such as our Mini Quick Release Plates
• Over Eighteen 1/4" hole options for mounting accessories
• 15mm Side Rod Support for EVF or Monitors
• Cold Shoe mounts on each end of the Handle
• Mounted via NATO Rail and can also slide on to both Left and Right Sides of Cage
• Comfortable and Ergonomic Grip Design

Optional Accessories Include: FF Single Rod Adapter, T5 SSD Holder, ARRI Rosette Adapters, 15mm Rods, 501 ARRI Baseplate, Rosette Extension Arms, Rosette Handgrips, Mini Quick Release Plates, Cine Magic Arm, 2 Pin LEMO to D-Tap Cable

Dimensions: 5” x 3” x 1”

Weighs: 6 oz

*Quick Guide for Camera Control Switch Modes:

"P": Canon EOS R, EOS R5C, EOS R6, LUMIX S1H, Panasonic GH5, S5, Fuji XT4, RED KOMODO,

"S": All Sony Cameras, URSA Mini, C300, C500, C70, Z CAM

Kondor Blue Full Cage with Top Handle for Blackmagic Pocket Cinema Camera 4K and 6K (BMPCC4K)

Features Include: Bubble Leveler, Cold Shoe Mounts, NATO Rails, and 15mm Rod Holder. Optional Accessories Include: FF Single Rod Adapter, T5 SSD Holder, ARRI Rosette Adapters, 15mm Rods, Baseplate, Rosette Arms, and hand grips.

The Kondor Blue Full Cage with Top Handle for BMPCC 4K/6K is a four-sided cage featuring an integrated bubble level and built-in shoe mount. The top handle attaches by quick release to a NATO rail that's screwed in on top of the cage.

The top handle provides a second shoe mount, multiple ARRI Accessory Mounts, and a single 15mm rod port for attaching a rod for an EVF, a lens motor, or other accessory. Three of the Accessory Mounts come with 3/8"-16 to 1/4"-20 bushings screwed into them so that you can mount 1/4"-20 accessories on top. These bushings are removable. The levers on the top handle are spring-loaded for more efficient use.

The cage provides access to all the ports, slots, and controls of the camera. It offers 1/4"-20 and 3/8"-16 threaded holes all around for attaching accessories as well as mounting onto a tripod. It has several threads on the bottom for extra flexibility in mounting on gimbals and similar camera supports. Your camera is secured to the cage using a supplied 1/4"-20 screw that screws in from the bottom.

Key Features

• Four-sided cage with integrated bubble level and shoe mount
• NATO rail top handle with anti-twist ARRI Accessory Mounts, 1/4"-20 bushings, shoe mount, and 15mm rod port
• 1/4"-20 and 3/8"-16 threaded holes all around
• 1/4"-20 and 3/8"-16 tripod mount threads
• Access to all ports, slots, and controls of the camera

Mount Types: Cage: 41 x 1/4"-20 Female, 2 x 3/8"-16 Female, Shoe Mount

Top Handle: 8 x ARRI Accessory Mounts (3/8"-16 to 1/4"-20 Bushing Inserted in Three of These), 15 mm Rod Port, Shoe Mount

Tripod Mount Type: 1/4"-20 and 3/8"-16

Dimensions: 7.75" x 4.25" x 1.75"

Weight: 1 lb

This universal lens mount is compatible with our Canon and RED cage systems and popular lens adapters.

This bracket solves the issue many operators face when adapting lenses on their cameras and dealing with loose lens mounts with too much play. This universal lens mount is designed to work on our Kondor Blue cages but may also work on other models as well. It has been tested effectively with brands such as Metabones, Canon, Wooden Camera, BOR, Revolva, and more.

The lens bracket mounts onto the cage using the included screws. It comes with 3 different height and screw options to allow universal compatibility and prevent any movement or twisting that may occur when using a Speedbooster or adapter with your lens.

Weight: 1.3 oz

RED Komodo, Canon C70 and R5

Bundle and Save!

Rig Consists Of:

• 1x Space Gray Full Cage for BMPCC 4K/6K
• 1x Universal 15mm LWS ARRI/501 Baseplate Side Loading
• 1x Rosette Arms, Grips & Clamp Bundle
• 2x 15MM PPSh Rod (12 Inches)
• 1x Cine V-Mount Plate for 15mm Rod Rigs
• 1x 14" DC to BMPCC 6K/4K Power Cable

This Blackmagic Pocket Cinema Camera 4k/6k Rig Consists Of:

• 1x Space Gray Full Cage for BMPCC 4K/6K
• 1x Universal 15mm LWS ARRI/501 Baseplate Side Loading
• 2x 15MM PPSh Rod (8" Inches)

Perfect 85mm Optical Height from Rods

Our BMPCC 4K/6K Battery Grip is available as a full cage setup with a Top Handle or as a Mod Kit for existing Cage owners.

The side rails in our Mod Kit are user-upgradeable, allowing customers to fully protect their cameras whether they are using the battery grip or not.
