Key Cage Features

Kondor Blue Canon C70 Ultimate Rig Consists Of:

• 1x C70 Cage w/ Trigger Top Handle

• 1x LWS ARRI Bridge Plate
• 2x 15MM PPSH Rods (12 Inches)
• 1x RF Cine Cap
• 1x Rosette Arm Bundle
• 1x V Mount Battery Plate
• 1x D-Tap to DC 2.5mm 15" Power cable

 Bridgeplate Features:

• ARRI-Standard Dovetail
• 15mm LWS Rod Support
• Quick Release Camera Plate System
• 1/4"-20 and 3/8"-16 Mounting Bolts
• 1/4"-20 and 3/8"-16 Tripod Mount Threads

Features:

• Pad
• Air-cushioned pad to perfectly set air pressure
• Removable/washable
• Includes Air Pump
• Mounts
• 12x Arri mounts
• When used in conjunction with Arri-Pin Rod Clamp they can be mounted to rail system
• 60mm standard spread
• 22x ¼-20 mounts
• Mounts on nato to mount directly to baseplate or dovetail
• Nato
• Rotating nato for use on chest, leg or low angle shots
• Can be bolted in place in either orientation for more security
• Tool built into shoulder pad
• Nato rail for fine tuning location of shoulder pad under crowded rig components
• Safety stops at each end of nato
• Versatility: Battery Plate for Counter Weight etc...

Product Highlights

LWS ARRI 15mm Bridge Plate

- Quick Release camera plate system

- ARRI-standard dovetail

- 15mm LWS rod support

- Rubber Padding

Key Features

• Our Bridge Plate supports 15mm LWS rods and the industry-standard ARRI dovetail connection making it ideal to build your large setups.

• 1/4"-20 and 3/8"-16 mounting screws

• 1/4"-20 and 3/8"-16 tripod mount threads

Dimensions

• Mount Types: 1/4"-20 and 3/8"-16 Male, 1/4"-20 and 3/8"-16 Female, ARRI-Standard Dovetail

• Rod Support: 15 mm LWS

• Dimensions: 3.5" x 4.3" x 1.3"

• Weight: 14.7 oz

• Our Quick Release Riser Plates provide the standard 85mm lens height for these cameras:

• Alexa Mini
• RED KOMODO
• URSA Mini (4K/4.6K/12K)
• BMPCC 6K Pro (With our Cage)
• Sony FX6
• Sony Venice

• Sony Rialto
• Sony F55 and F5
• Canon C70 (With Our C70 Bottom Plate)

COMING SOON - Camera Specific Riser Plates to Support the following:

The Extensions have holes that allow users to tighten parts securely to the Base Extension Rod.

The Wheeled Lens Support is intended for lenses that do not have room for the V Lens Support and can rest on areas of the lens that still require rotation.

The single-sided rail block allows users to mount or remove support without having to remove other accessories that are mounted along with their rig.

Camera Lens Support Kit Features:

• Single-sided rail block
• Base Extension Rod (13.5mm travel)
• Wheeled Lens Support
• V Lens Support
• 3mm mount - 15mm extension
• ¼” 20 mount - 15mm extension
• ⅜” 16 mount - 15mm extension

ARRI Rosette Adjustable Length Extension Arm

Product Highlights

- ARRI-compatible rosettes.

- Captive Locking Lever, Cable Clips.

- Aerospace-Grade Aluminum.

- 8 to 11.5" Adjustable Length.

Key Features

• An extension arm to add handgrips or other accessories to the side of your rig using ARRI-compatible rosettes.

• The length of the arm can be adjusted from 8" to 11.5" using the center screw, which is tightened by a blue captive locking lever.

• There are also two cable clips on the side of the arm that will keep your cables neat and secure.

• Usually paired with our Rosette Hand Grips and Dual 15mm Rod Clamp.

• This extension arm can be used with almost any accessory that uses ARRI-compatible rosettes.

Dimensions

• Connectors: 2 x ARRI-Style Rosettes

• Dimensions: 7.91" x 1.57" x 1.29"

• Adjustment Range: 8”-11.5"

• Weight: 6.3 oz

Product Highlights

- Side Handgrip.

- Thumb Lever for Quick Adjustments.

- ARRI-Type Rosette and Locking Lever.

- Textured Black Rubber Grip.

Key Features

• Made of rubber for a comfortable grip and temperature control.

• Features a Thumb lever for Quick Rosette Adjustments on the go! Sold Individually as well.

• This rosette handle can be attached to any ARRI-compatible rosette system with an M6 threaded mounting hole.

• The rubber handle features a high-relief texture for a non-slip grip.

• Compatible with ARRI rosettes with M6 thread.

Dimensions

• Material of Construction: Aerospace-Grade Aluminum, Rubber

• Mounting: ARRI-Type Rosette with M6 Thread

• Dimensions: 6.8" x 1.8" x 1.4"

• Weight: 7.2 oz

Product Highlights

- ARRI-style rosettes

- Lightweight

- Durable

- Aerospace Grade Aluminum

Key Features.

• Our double rod clamp allows you to attach and adjust rosette-mount hand grips on your shoulder rig.

• This dual rod clamp mounts onto two separately available standard 15mm camera rods sold separately.

Dimensions

•Mounting: 15mm Dual Rod Block, 2 x Rosettes with M6 Thread (31.8mm)

•Dimensions: 4.6" x 1.26" x 1.26"

•Weight: 4.1 oz

Product Highlights

- Connects via ARRI Rosettes.

- Provides Quick Adjustments.

- Aerospace-Grade Aluminum.

Key Features

• The bundle includes a right and left pair of hand grips, a right and left pair of adjustable extension arms, and a standard 15mm rod block.

• The aluminum handgrips are lined with textured rubber for a comfortable grip, and they connect using quick-release rosettes.

• The extension arms allow you to connect the handles, and they can adjust to your preferred position and length.

• The extension arms then connect to the 15mm rod block, which can be mounted on a pair of separately available 15mm rods to complete your shoulder rig.

Dimensions

• Weight: 31.1 oz.

Product Highlights

- Features multiple DC outputs.

- Can charge a Battery.

- Aerospace Grade Aluminum.

- 15mm rod connectors.

Key Features

• Our Thin V-Mount Battery Plate features multiple DC outputs (5, 7.4, 12, 15V, and a D-Tap), enabling you to power multiple devices simultaneously.

• Battery Plate also features two 15mm rod connectors, allowing you to mount it to an existing rig via two blue locking levers. 15mm rods sold separately.

• The plate includes a switchable 7.4/8.4V 1.35mm barrel output, a 5V 2.5mm barrel output, a 12V 2.5mm barrel output, and a D-Tap output.

• The 2.5mm DC barrel charger input allows you to charge the mounted battery with our AC Charger Cable sold separately. This port will also allow you to power your plate and accessories if no battery is mounted. (BLINKING light means charger cable is plugged in but no battery is mounted, GREEN light means the battery is fully charged, RED light means Battery is charging)

• Power Input:

1. DC Jack: 19V

• Power Output:

1. D-Tap: 14.4V
2. DC Jack: 15 V
3. DC Jack: 12 V
4. DC Jack: 7.4 to 8.4 V
5. DC Jack: 5 V

Dimensions/Weights

• Dimensions: 5.03" x 4.41" x 1.96"

• Weight: 11.3 oz

15mm ARRI-Pin Rod Clamp

Product Highlights

- Add a Rod on any ARRI locator pin mount

- Lightweight

- Durable

- Aerospace Grade Aluminum

Key Features

• Normally used to attach a Follow Focus Gear to the rig without the need of a baseplate system.

• The durable aluminum rod clamp attaches to the cage with either a 3/8 or 1/4 bolt and features locating pins to prevent twisting and loosening. A blue locking thumb screw tightens around a separately available 15mm rod.

Dimensions

• Mounting:

• Dimensions:

• Weight:

Product Highlights

- PPSh Barrel Design

- Lightweight

- Durable

- Aerospace Grade Aluminum

- Extendable Options

Key Features

• Lightest aluminum rod in the industry without sacrificing strength.

• Used for accessories like follow focus, matte box, lens support, servo motors, and more.

• Extend to custom length with M12 Rod Extension Connectors (sold separately).

Dimensions

• Diameter: 15mm

• Thread size: M12

• Length: 3"

• Weight: 0.5 oz

Product Highlights

- 1/4", 3/8", and ARRI Pin compatibility.

- Provides quick release functionality.

- Aerospace Grade Aluminum.

- Anti-Twist Set Screw for Male Plate.

Key Features

• This camera quick release plate is made up of two parts, a male and a female dovetail plate.

• It provides quick release functionality between cameras and accessories including and not limited to: Magic Arms, LED Lights, EVF Mounts, Monitors, Microphones, Recorders, Flashes, Gimbals and More!

• Stronger than the competition. Secure & Solid Mechanism.

• Features Anti Twist Set Screw for male plate.

• Comes with 2 Allen Wrenches 2 screws and a rubber washer.

• Additional Anti-Twist Arri Locator Pin and SmallHD Spacer Plates are also available (Sold Separately).

Dimensions

• Mounting: 2 x 1/4"-20 Screws, 2 x 3/8"-16 Screws,

• Dimensions: 1.87" x 1.12" x 0.65"

• Weight: 1.3 oz

• Sliding Dovetail Design
• Balances Front- or Back-Heavy Equipment
• Safety Latch
• 12 x 1/4"-20 and 5 x 3/8"-16 Threads
• Weighs 8oz / 225g

Features

• Allows you to mount our popular Mini Quick Release Plates to any Cold Shoe or Hot Shoe Receiver
• 1/4"-20 screw provided
• Lifetime Warranty

Weight:

Dimensions:
